Reference

Setting range of thermal trips

Standard power ratings of 3-phase motors, 50/60Hz in category AC-3

400/415V

500V

690V

P,kW

Icu,kA

Ics,%

P,kW

Icu,kA

Ics,%

P,kW

Icu,kA

Ics,%

GV2ME04

0.40…0.63A

0.12

-

-

-

-

-

0.37

-

-

GV2ME05

0.63…1.00A

0.25

-

-

-

-

-

0.55

-

-

GV2ME06

1.00…1.60A

0.55

-

-

0.55

-

-

0.75

-

-

GV2ME07

1.60…2.50A

0.75

-

-

1.1

-

-

1.5

3

75

GV2ME08

2.50…4.00A

1.5

-

-

2.2

-

-

3

3

75

GV2ME10

4.00…6.30A

2.2

-

-

3

50

100

4

3

75

GV2ME14

6.00…10.0A

4

-

-

5.5

10

100

7.5

3

75

GV2ME16

9.00…14.0A

5.5

15

20

7.5

6

75

9

3

75

GV2ME20

13.0…18.0A

7.5

15

50

9

6

75

15

3

75

GV2ME21

17.0…23.0A

9

5

40

11

4

75

18.5

3

75

GV2ME22

20.0…25.0A

11

15

40

15

4

75

-

-

-

GV2ME32

24.0…32.0A

15

10

50

18.5

4

75

22

3

75
